ZLYJ Series High Torque Ib Ntsia Hlau Extruder Gearbox

Lus piav qhia luv luv:

ZLYJ series siab torque gearbox yog ib hom tshwj xeeb iav chav tsev tshawb fawb thiab tsim los ntawm importing thev naus laus zis tshaj plaws ntawm cov hniav tawv hauv ntiaj teb. Lub gearbox muaj siab axial thrust, tso zis torque thiab lub zog, thiab nws yog dav siv nyob rau hauv lub teb ntawm roj hmab thiabyas extrusion.

Product Detail

Khoom cim npe

Cov ntaub ntawv yooj yim

Lub zog nkag 10 KW-633 KW
Ntsia Hlau Diameter 45 - 150 mm
Tso zis Torque 1528N · m ~ 42338N · m
Input Ceev 600 - 1500RPM
Cov zis ceev Raws li Ratio
Cov khoom siv iav 20CrNi2MoA Siab - Lub zog Alloy Steel
Khoom siv tsev Cast Iron
Gear processing CNC sib tsoo
Hom ntawm Bearings ZWZ, NSK, FAG, thiab lwm yam.
Hom Roj Foob FAG, NAK, thiab lwm yam.
Nto Hardness ntawm Gears HRC54 ~ 62
Gear Accuracy Qib 6
Kev kho cua sov Carburizing, quenching
Txias hom Coil Cooler, Tubular Cooler
Tso zis hom Hollow Ncej tso zis
Hom tswv yim Khoom Ncej


Product Description

ZLYJ series siab torque gearbox yog ib hom tshwj xeeb iav chav tsev tshawb fawb thiab tsim los ntawm importing thev naus laus zis tshaj plaws ntawm cov hniav tawv hauv ntiaj teb. Lub gearbox muaj siab axial thrust, tso zis torque thiab lub zog, thiab nws yog dav siv nyob rau hauv lub tshav pob ntawm roj hmab thiab yas extrusion.

Khoom Feature
1.Compact tsim.
2 High hardness, siab toughness thiab siab precision.
3. Tsawg suab nrov.
4.High axial bearing muaj peev xwm.
5. Kev ntseeg siab ua haujlwm siab.
6.Perfect roj to tiv thaiv kev ua tau zoo.
7.Excellent tshav kub dissipation kev ua tau zoo.
8.Forced lubrication system nrog nce lub thawv nto cheeb tsam

Technical Parameter

Spec. (ZAJ) Ratio Range Lub cev muaj zog (KW) Input ceev (RPM) Cov zis torque (N·M) Ntsia Hlau Diameter (mm)
133 6.3/8/10/12.5/14/16/18/20 10-30 Nws ≦1500 1528-2174 Ib Ø 45/50
146 6.3/8/10/12.5/14/16/18/20 12-54 : kuv ≦1500 3183-3438 ib Ø 55
160 6.3/8/10/12.5/14/16/18/20 14-59 : kuv ≦1500 3700-3838 Ib Ø 65
180 6.3/8/10/12.5/14/16/18/20 23-97 : kuv ≦1500 5600-6600 Nws Ø 65
200 6.3/8/10/12.5/14/16/18/20 33-110 : kuv ≦1500 7100-8400 Nws Ø 75
225 6.3/8/10/12.5/14/16/18/20 43-170 : kuv ≦1500 10792-11352 ib Ø 90
250 6.3/8/10/12.5/14/16/18/20 54-208 : kuv ≦1500 12961-13752 Ib Ø 100
280 6.3/8/10/12.5/14/16/18/20 88-330 : kuv ≦1500 21010-22738 ib Ø 105 / Ø 110
320 6.3/8/10/12.5/14/16/18/20 128-455 : kuv ≦1500 28968 - 32597 Ib Ø 120
360 6.3/8/10/12.5/14/16/18/20 156-633 : kuv ≦1500 35559-42338 Ø 130/150

Daim ntawv thov
ZLYJ series siab torque gearbox yog dav siv nyob rau hauv cov log tsheb roj hmab, hlau thiab cable, qhov sib sau, kav, xov hlau, roj hmab rau conveyor siv, yas zaj duab xis / ntawv xws li. ntim zaj duab xis, hnab tote, sab nraum zoov tarps, ntim khoom, thermal rwb thaiv tsev board (polystyrene).

FAQ

Q: Yuav ua li cas xaiv a gearbox thiabiav ceev reducer?

A: Koj tuaj yeem xa mus rau peb cov ntawv teev npe los xaiv cov khoom lag luam tshwj xeeb lossis peb tuaj yeem pom zoo rau cov qauv thiab cov lus qhia tshwj xeeb tom qab koj muab lub zog xav tau, tso zis nrawm thiab nrawm piv, thiab lwm yam.

Q: Peb tuaj yeem lav tau li caskhoomzoo?
A: Peb muaj cov txheej txheem tsim khoom nruj heev thiab kuaj txhua qhov ua ntej xa khoom.Peb lub thawv iav reducer tseem yuav ua tiav qhov kev ua haujlwm sib raug zoo tom qab kev teeb tsa, thiab muab cov ntawv xeem. Peb cov khoom ntim yog nyob rau hauv cov rooj ntoo tshwj xeeb rau kev xa tawm kom ntseeg tau tias kev thauj mus los zoo.
Q: Vim li cas kuv thiaj xaiv koj lub tuam txhab?
A: a) Peb yog ib qho ntawm cov tuam txhab ua lag luam thiab cov khoom xa tawm ntawm cov khoom siv sib kis.
b) Peb lub tuam txhab tau tsim cov khoom siv iav rau txog 20 xyoo ntxiv nrog kev paub nplua nujthiab advanced technology.
c) Peb tuaj yeem muab qhov zoo tshaj plaws thiab kev pabcuam zoo tshaj plaws nrog cov nqi sib tw rau cov khoom.

Q: yog dab tsikoj MOQ thiabcov ntsiab lus ntawmkev them nyiaj?

A: MOQ yog ib chav tsev.T / T thiab L / C tau txais, thiab lwm cov nqe lus kuj tuaj yeem sib tham.

Q: Koj puas tuaj yeem muab cov ntaub ntawv cuam tshuam rau cov khoom?

A:Yog lawm, peb tuaj yeem muab cov ntaub ntawv feem ntau suav nrog tus neeg teb xov tooj phau ntawv qhia, daim ntawv tshaj tawm kev soj ntsuam zoo, kev pov hwm kev thauj mus los, daim ntawv pov thawj ntawm keeb kwm, daim ntawv teev npe, daim ntawv them nyiaj ua lag luam, daim nqi thauj khoom, thiab lwm yam.
