ZELYJ 200/225/250/280 Ib Leeg Ntsub Ntsim Txo Gearbox nrog Spine Ncej

Cov lus piav qhia luv luv:

Zlyuj Series Gearbox rau tib ntsia hlau Extruder yog hom tshwj xeeb tshawb fawb thiab tsim los ntawm kev xa tawm cov hniav nyuaj tshaj plaws hauv ntiaj teb. Rau tsis ntev los no kaum xyoo, nws yog dav siv nyob rau hauv sab saum toj thiab nruab nrab - cov roj hmab yas, roj hmab, thiab tshuaj lom neeg f ...

Khoom Qhia Qhia

Khoom Ntawv

Khoom Piav Qhia
Zlyuj Series Gearbox rau tib ntsia hlau Extruder yog hom tshwj xeeb tshawb fawb thiab tsim los ntawm kev xa tawm cov hniav nyuaj tshaj plaws hauv ntiaj teb. Rau tsis ntev los no kaum xyoo, nws yog dav siv nyob rau hauv sab saum toj thiab nruab nrab - cov roj hmab, thiab tshuaj lom neeg zoo, thiab muaj lub koob npe loj dua hauv kev lag luam.
Khoom Feature
1.Qhov tag nrho tshuab zoo nkauj thiab ywj pheej, uas tuaj yeem siv ob qho tib si ntsug thiab kab rov tav. Nws tuaj yeem haum ntau qhov yuav tsum tau ua ntawm sib sau ua ke.
2.Qhov cov ntaub ntawv iav thiab lub thawv qauv tau tsim qauv zoo ntawm lub khoos phis tawm. Cov txiaj ntsig yog ua los ntawm sab saum toj - Qeb Tsawg Cov Hlau Roj Hmab Nrog Rau Qib 6 Precision ntawm Cov Hniav Tom qab cov pa roj carbon nkag, kev sib tsoo thiab sib tsoo. Lub hardness ntawm cov hniav nto yog 54 - 62 hrc. Lub iav khub tau ruaj khov khiav, lub suab qis, thiab muaj kev ua haujlwm siab.
3.Qhov sib koom ua ke txuas tau qhov precision muaj qhov precision ntawm radial khiav - tawm thiab kawg ntsej muag khiav - tawm ntawm theem thoob ntiaj teb, thiab tuaj yeem txuas tau yooj yim nrog tus ntsia hlau ntawm lub tshuab chim.
4.Qhov cov qauv coj ntawm cov tso zis tawm muaj cov qauv tshwj xeeb, uas tuaj yeem ua tau zoo ntev lub neej ntawm lub bearings.
5.Txhua qhov txheem xws li cov kabmob, roj foob, roj roj twj tso kua mis, thiab lwm yam yog xaiv cov khoom lag luam nto moo hauv tsev. Lawv tuaj yeem xaiv los ntawm cov khoom lag luam txawv teb uas yog qhov yuav tsum tau ntawm cov qhua tuaj noj mov.

Kev Lag Luam Kev Lag Luam

ZELYJ Series Feem ntau Cov hwj chim tawm (KW) Tawm tswv yim ceev (RPM) Tso zis ceev (RPM) Ntsia Hlau Kab Ciam (Mm)
112 8/10 / 12.5 5.5 800 100 35
133 8/10 / 12.5 / 14 / 16/1/1/1 8 800 100 50/45
146 8/10 / 12.5 / 14 / 16/1/1/1 12 900 90 55
173 8/10 / 12.5 / 14 / 16/1/1/1 18.5 900 90 65
180 8/10 / 12.5 / 14 / 16/1/1/1 22 960 100 65
200 8/10 / 12.5 / 14 / 16/1/1/1 30 1000 80 75
225 8/10 / 12.5 / 14 / 16/1/1/1 45 1000 80 90
250 8/10 / 12.5 / 14 / 16/1/1/1 45 1120 70 100
280 8/10 / 12.5 / 14 / 16/1/1/1 64 960 60 110/105
315 8/10 / 12.5 / 14 / 16/1/1/1 85 960 60 120
330 8/10 / 12.5 / 14 / 16/1/1/1 106 960 60 130/150
375 8/10 / 12.5 / 14 / 16/1/1/1 132 960 60 150/160
420 8/10 / 12.5 / 14 / 16/1/1/1 170 960 60 165
450 8/10 / 12.5 / 14 / 16/1/1/1 212 1200 60 170
500 8/10 / 12.5 / 14 / 16/1/1/1 288 1200 60 180
560 8/10 / 12.5 / 14 / 16/1/1/1 400 1200 60 190
630 8/10 / 12.5 / 14 / 16/1/1/1 550 1200 60 200

Daim ntawv thov
ZELL Series Gearbox Yog dav siv nyob rau hauv sab saum toj thiab nruab nrab - Cov yas yas, roj hmab, thiab tshuaj fiber ntau extruders.

Cov FAQ

Q: Yuav ua li cas xaiv A tus thawv thiabIav ceev reducer?

A: Koj tuaj yeem xa mus rau peb cov catalog kom xaiv cov khoom lag luam tshwj xeeb lossis peb tuaj yeem pom zoo cov qauv thiab cov zis kom ceev thiab nrawm, thiab lwm yam.

Q: Yuav ua li cas peb tuaj yeem lavkhoomZoo?
A: Peb muaj cov txheej txheem tsim cov txheej txheem ntau lawm thiab sim txhua ntu ua ntej xa khoom.Peb lub iav lub thawv Reducer tseem yuav ua tiav cov kev xeem ua haujlwm ua haujlwm tom qab kev teeb tsa, thiab muab daim ntawv qhia kev xeem. Peb cov ntim yog cov ntoo ntoo tshwj xeeb rau kev xa tawm kom ntseeg tau tias qhov zoo ntawm kev thauj mus los.
Q: Vim li cas kuv thiaj li xaiv koj lub tuam txhab?
A: A) Peb yog ib qho ntawm cov ua lag luam thiab cov khoom lag luam ntawm cov iav kis khoom siv.
b) Peb lub tuam txhab tau ua cov khoom iav tsim kom ntev li 20 xyoo ntxiv nrog kev nplua nuj ntauthiab thev naus laus zis.
c) Peb tuaj yeem muab qhov zoo tshaj plaws zoo thiab kev pabcuam zoo tshaj plaws nrog cov nqi sib tw rau cov khoom lag luam.

Q: Dab tsi yognej li MOQ thiabCov ntsiab lus ntawmkev them nyiaj?

A: MOQ yog ib chav .t / t thiab L / C yog txais, thiab lwm cov lus kuj tseem tuaj yeem sib ceg.

Q: Koj puas tuaj yeem muab cov ntaub ntawv cuam tshuam rau khoom?

A:Yog lawm, peb tuaj yeem muab cov ntaub ntawv feem ntau nrog rau phau ntawv tsav tsheb, xa ntawv pov thawj zoo, daim ntawv pov thawj kev tiv thaiv, cov ntawv sau nqi, cov nqi lag luam, thiab lwm yam.
